WQ-320 Screen Printing Machine
WQ-320 Screen Printing Machine

Digital Screen Printing Machine

Features

Model WQ-320
Printing speed 10-50 time / minute
Max. unwinding diameter   450mm
Max. web width 320mm
Max. printing width 300mm
Max. printing length 320mm
Accuracy ±0.15mm
Get a Quote PDF Datasheet
Share:
Product Details
Main Features

The machine is used for printing reel material, such as PVC, OPP, Dacron, Security mark, adhesive tape, etc. The material towing is controlled by servo motor, the main machine driving part adopts pneumatic device,and the web-guiding is tracked by photocells. The machine has the characteristics of high accurate color register, steady material-feeding, automatic counter and alarm, convenient adjustment and compact sturcture, etc.



Main Technical Parameters
Model WQ-320
Printing speed 10-50 time / minute
Max. unwinding diameter 450mm
Max. web width 320mm
Max. printing width 300mm
Max. printing length 320mm
Accuracy ±0.15mm
Main motor power 1200w
Oven power 4100w
Dimensions(L×W×H) 2400x950x1500mm
Oven dimension(L×W×H) 1750x600x1800mm
Machine weight about 1100kgs option: UV Dryer System
